TZM110W (TZM100W)

Engine model

1P51QMH

Dimension

1910*680*1100mm

Cylinder

Single Cylinder

Wheel Base

1290mm

Valve

4 Stroke

Min Ground Clearance

120 mm

Cooling Type

Air-cooling

Seat Height

810 mm

Bore* Stroke

51*54 mm

Dry weight

94 kg

Compression ratio

9.5:1

Max. load

150 kg

Displacement

110.3 ml

Fuel tank capacity

5 L

Starter

Electrical/Kick

Max. speed

82km/h

Ignition

Transistor

Front Brake

Disc / Hand

Rated power

5.5 Kw 8000±500 r/min

Rear Brake

Drum /Hand

Max. Torque

7.8 Nm 6500±500 r/min

Transmission

Belt + Shaft

Fuel consumption

2.3L/100KM

Front Tire

90/90-12 tubeless

Clutch type

Automatic

Rear Tire

350-10 tubeless

Package

SKD

CKD

Packing status

Carton with iron bracket

Packing size

1700*570*830mm

Qty in container

26/20GP, 56/40GP, 84/40HQ

110 units/40HQ

M.O.Q

26 UNITS
