CZM250G-3
Z-MOTOS
This cruiser can use 150cc, 200cc and 250cc balance shaft engines.
The most popular options are front bumper, big rear carrier, rear side boxes, Front decorative lamps and remote control ect.
Technical specifications
Engine
Frame
Engine model
253MM
Dimension
2130*800*1070mm
Cylinder
Double-Cylinders
Wheel Base
1430 mm
Valve
4-stroke
Dry weight
158 kg
Cooling
Oil-Cooled
Max. load
160 kg
Bore* stroke
53*53*2
Max. speed
118 km/h
Displacement
233 ml
Clutch type
Manual
Starter
Electrical
Brake(Fr./ Rr.)
Disc/Hand; Disc/Foot
Ignition
Transistor
Tank Capacity
20 L
Rated power
12 kw 8500±500 r/min
Wheel
Alloy or spoke Wheel
Max.torque
15N.m 6000±500 r/min
Tyre size
110/70-17, 150/70-17
Package
CBU/SKD
CKD
Packing status
Carton with iron bracket
Carton with wooden bracket
Packing size
1980*570*870mm
Quantity in container
22/20GP, 48/40GP, 72/40HQ
M.O.Q
22 UNITS
