TZM150N-2B

Engine model

157QMJ

Dimension

1900*720*1060mm

Cylinder

Single

Wheel Base

1300mm

Valve

4 stroke

Dry weight

111 kg

Cooling Type

Air-cooling

Max. load

150 kg

Bore* Stroke

57.4*57.8mm

Max. speed

80 km/h

Displacement

149.5 ml

Clutch type

Automatic

Starter

Electrical/Kick

Front Brake

Disc / Hand

Ignition

Transistor

Rear Brake

Drum / Hand

Rated power

7.0 Kw 7500±500 r/min

Wheel

10 inch Alloy Wheels

Max. Torque

9.8 Nm 6000±500 r/min

Transmission

Belt + Shaft

Fuel consumption

2.6L/100KM

FR & RR Tire

350-10 tubeless

Package

SKD

CBU

Packing status

Carton with iron bracket

Carton with iron bracket

Packing size

1780*570*860mm

1820*570*1150mm

Qty in container

26/20GP, 52/40GP, 78/40HQ

24/20GP, 50/40GP

M.O.Q

26 units
