Each electric vehicle has many different optional Status, different status have different prices. So if you want to know the exact price of any model, please tell me motor power and battery capacity you need. If you don't know how to chosen them, you can tell me your requirements for max speed and mileage for one charge, and then I will match you with suitable battery and motor according to your requirements. If you can tell me the local climate, terrain and Target consumers, This is of great reference value for us to determine the product status.
The battery and motor of this electric vehicle have the following options:
DC Motor: 60V500W-1500W, 72V800W-2000W motors.
Lead-acid battery: 60V20Ah-32Ah, 72V20Ah-32Ah.
Lithium battery: 60V20Ah-60Ah, 72V20Ah-50Ah.
The motor power mainly affects the maximum speed and climbing ability, while the battery capacity mainly affects the driving range one charge. But matching a high-power motor with a high-capacity battery is a bigger principle.
SPECIFICATION
| Dimension | 1830*700*1100 mm | Climbing Capacity | 15°-20° |
| Wheel base | 1330 mm | Battery Type | Lead-Acid/Lithium |
| Dry weight | 62 kg (without batteries) | Battery Max. power | 72V32Ah/72V50Ah |
| Max. load | 150 kg | Charging voltage | AC110V--240V |
| Max. speed | 35-70 km/h | Charging time | 6-8 hours |
| Brake(Fr./Rr.) | Disc / Disc | Continues mileage | 40-105km |
| Wheel type | 10 inch Iron/Alloy wheels | Packing status | Carton with iron bracket |
| Front tire | 350-10 or 90/90-10 Tire | Packing size | 1700*570*860mm |
| Rear tire | 350-10 or 90/90-10 Tire | Quantity in container | 26/20GP, 56/40GP, 84/40HQ |
| Motor type | 500-2000W brushless | M.O.Q | 26 units |
| Working Voltage | 72V/60V |
|
|
