CZM200E-2
Z-MOTOS
This cruiser can use 150cc, 200cc and 250cc balance shaft engines.
The most popular options are front bumper, big rear carrier, rear side boxes, Front decorative lamps and remote control ect.
Technical specifications:
Engine
Frame
Engine model
163FML Balance Shaft
Dimension
2170*840*1140 mm
Cylinder
Single-Cylinder
Wheel Base
1430 mm
Valve
4-stroke
Dry weight
148 kg
Cooling
Air-Cooled
Max. load
160 kg
Bore* stroke
63.5*62.2mm
Max. speed
110 km/h
Displacement
197 ml
Clutch type
Manual
Starter
Electrical / Kick
Brake(Fr./ Rr.)
Disc/Hand; Disc/Foot
Ignition
C.D.I
Tank Capacity
13 L
Rated power
10.2 kw 8500 r/min
Wheel
Alloy Wheel
Max.torque
13.8N.m 6000 r/min
Tyre size
110/90-16, 130/90-15
Package
CBU/SKD
CKD
Packing status
Carton with iron bracket
Cartons
Packing size
1980*570*860 mm
Quantity in container
22/20GP, 48/40GP, 72/40HQ
120 units/40HQ
M.O.Q
48 UNITS
Detailed Pictures:
