Each electric vehicle has many different optional Status, different status have different prices. So if you want to know the exact price of any model, please tell me motor power and battery capacity you need. If you don't know how to chosen them, you can tell me your requirements for max speed and mileage for one charge, and then I will match you with suitable battery and motor according to your requirements. If you can tell me the local climate, terrain and Target consumers, This is of great reference value for us to determine the product status.
The battery and motor of this electric vehicle have the following options:
DC Motor: 48V250W, 48V350W, and 48V400W motors.
Lead-acid battery: 48V12Ah, 48V20Ah.
Lithium battery: 48V20Ah, 48V30Ah.
The motor power mainly affects the maximum speed and climbing ability, while the battery capacity mainly affects the driving range one charge. But matching a high-power motor with a high-capacity battery is a bigger principle.
SPECIFICATION
| Dimension | 1430*670*980 mm | Climbing Capacity | 8°-12° |
| Wheel base | 990mm | Controller type | 6 tubes 21A-25A |
| Dry weight | 32 kg without battery | Battery Type | Lead-acid/ Lithium |
| Max. load | 100 kg | Battery Power | 48V12Ah/48V20Ah/48V30Ah |
| Max. speed | 25-32 km/h | Charging voltage | AC110V--240V |
| Brake (Fr./Rr.) | Drum/Hand, Drum/Hand | Charging time | 4-5 hours |
| Wheel type | 10 inch iron wheels | Continues mileage | 45-60km |
| FR & RR Tire | 14*2.5 or 250-10 tires | Packing status | Carton |
| Meter & Headlight | LED | Packing size | 1320*330*660mm |
| Gear | 1 | Quantity in container | 87/20GP, 213/40GP, 245/40HQ |
| Motor type | 250W-400W brushless | M.O.Q | 80 units |
| Working Voltage | 48V |
|
|
