TZM110J-3 (TZM100J-3)

Engine model

1P51QMH

Dimension

1840*630*1080mm

Cylinder

Single

Wheel Base

1260mm

Valve

4 stroke

Ground clearance

180 mm

Cooling Type

Air-cooling

Seat Height

750 mm

Bore* Stroke

51*54mm

Dry weight

87 kg

Displacement

110.3 ml

Max. load

150 kg

Starter

Electrical/Kick

Max. speed

80km/h

Ignition

Transistor

Front Brake

Disc /Hand

Rated power

5.5 Kw 8000±500 r/min

Rear Brake

Drum /Hand

Max. Torque

7.8 Nm 6500±500 r/min

Transmission

Belt+Shaft

Fuel consumption

2.2L/100KM

FR & RR Tire

90/90-10 or 350-10 tubeless

Package

SKD

CBU

Packing status

Carton with iron bracket

Carton with iron bracket

Packing size

1680*460*860mm

1750*560*1150mm

Qty in container

32/20GP, 70/40GP, 105/40HQ

26/20GP, 52/40GP

M.O.Q

32 UNITS

26 UNITS
